IF YOUR INTERNET SERVICE PROVIDER DOES NOT SUPPORT V.90 DO NOT UPGRADE YOUR MODEM! UPGRADING YOUR MODEM WILL RESULT IN LOWER CONNECTION SPEED!

EVEN IF YOUR SERVICE PROVIDER SUPPORTS V.90, UPGRADING YOUR MODEM TO V.90 MAY NOT RESULT IN HIGHER CONNECTION SPEED OR BETTER PERFORMANCE!

IMPORTANT : Do not use any of the upgrade program in NT operating system

Instruction for download:

1. Click on the model number of your modem.

2. Save the file on your hard drive.

3. After the download is completed, run the file and it will self-extract.

4. After the files are extracted, please read the "readme.txt" for instruction on how to  upgrade your modem.



 CMV1456VQH-PLUS & CMV1456VQH-RV.90 & CMV1456VQE-R
CMV1456VQH-PLUS and CMV1456VQH-RV.90

INTERNAL modem : If you don't know what your model # is, please go to control panel ( if using windows 95) -> modem -> click on diagnostics -> highlight the COM port of the modem you are using -> click on More Info. Check the ati3 command, if    the number is V0.519 or V1.009-K56_DLP or V2.010_K56_DLP, then the upgrade is for your modem. If the number does not match, please don't download the upgrade.


CMV1456VQE-R

EXTERNAL modem : Your model # is located on the bottom of the unit.

<><If you need to go back to the K56 Flex firmware version, just run the upgrade program one more time.><>



CMV1456VQH-X   &  CMV1456VQE-X
CMV1456VQH-X

If you don't know what your model # is, please go to control panel ( if using windows 95) -> modem -> click on diagnostics ->highlight the COM port of the modem you are using -> click on More Info. Check the ati3 and ati6 respectively, if the number for ati3 is OK, and for ati6 is 56K VOICE/DATA/FAX Modem , then the upgrade is for your modem. If the number does not match, please don't download the upgrade.

CMV1456VQE-X ( EXTERNAL )

 Your model # is located on the bottom of the unit.


  If you need to go back to the previous X2 firmware version,  just download the following firmware file.

Back to X2  Internal ONLY!

Be sure to read the README.txt after extracting this file.

Back to X2  External ONLY!

Be sure to read the README.txt after extracting this file.



CMV56KRA
CMV56KRA

If you don't know what your model # is, please go to control panel ( if using windows 95) -> modem -> click on diagnostics -> highlight the COM port of the modem you are using -> click on More Info. Check the ati3 command, if the number is V1.002.C04-K56_DLP, then the upgrade is for your modem. If the number does not match, please don't download the upgrade.

K56 Flex
<>< Go back to the K56 Flex firmware version, please download the file. ><>



CMV56KCL

CMV56KCL

Be sure to read the README.txt after extracting this file.

IMPORTANT READ BELOW FIRST

This is a V.90 single mode firmware update. It supports V.90 speeds ONLY. Perform this upgrade only if your ISP supports V.90 as it will NOT support X2 after upgrading. If they do not, you will experience slow connections. Do not reboot or do anything that will interrupt the flash update.

If you don't know what your model # is, please go to control panel ( if using windows 95) -> modem -> click on diagnostics ->highlight the COM port of the modem you are using -> click on More Info. Check the ati3 and ati6 respectively, if the number for ati3 is CLMD-56xx, and for ati6 is US , then the upgrade is for your modem. If the number does not match, please do not download the upgrade.




CMV1456VQH-P
   IMPORTANT READ BELOW FIRST
This driver requires

Intel Pentium 166MHz and up

AMD K6 266 MHz with MMX and up

Cyrix 6X86MX 266 MHz with MMX and up

     Cyrix MediaGX with MMX is currently unsupported.

        We will try to support it in the near future.



 CMV1456VQH-P
 README
 UNINSTALL

Please download all three files above. It is important for you to read the README file first before the using the new driver with V.90 and K56 Flex capability. Use the UNINSTALL file to remove the old driver in your hard drive. This driver file is the same with the driver in the download section.

If you don't know what your model # is, please go to control panel ( if using windows 95) -> modem -> click on diagnostics -> highlight the COM port of the modem you are using -> click on More Info. Check the ati3, if the respond for ati3 is PCtel then the upgrade is for your modem. If the number does not match, please don't download the upgrade. "



CMVRA56K
CMVRA56K

"If you don't know what your model # is, please go to control panel ( if using windows 95) -> modem -> click on diagnostics -> highlight the COM port of the modem you are using -> click on More Info. Check the ati3 and also ati6 command respectively, if the number for ati3 is V1.120-K56_DLP, and for ati6 is RCV56DPF L8570A Rev 35.0/34.0 , then the upgrade is for your modem. If the number does not match, please don't download the upgrade. "



CM1456VQC-T

CM1456VQC-T

Run the Flash.exe file after extraction to upgrade to V.90

Please look at the PCMCIA card for the model # V1456VQC-T4. If you do not see this model # on the PCMCIA itself, do not use this upgrade program.



CM56KPCMCIA
CM56KPCMCIA

Instruction to upgrade

This upgrade program requires Windows 95 operating system

Be sure to read the README.txt after extracting this file.

Please look at the PCMCIA card for the model # FM566C-KF. If you do not see this model # on the PCMCIA itself, do not use this upgrade program.

DO NOT upgrade if your PCMCIA is already at dual mode of V.90 and K56 Flex



CM56KPCMCIA-T
CM56KPCMCIA-T

This upgrade program requires Windows 95 operating system

Be sure to read the README.txt after extracting this file.

Please look at the PCMCIA card for the model # FM56KLF. If you do not see this model # on the PCMCIA itself, do not use this upgrade program.

DO NOT upgrade if your PCMCIA is already at dual mode of V.90 and K56 Flex



 CMV1456VQH-2MRA
The modem is already in dual mode of V.90 and K56 Flex.



 CMV1456VQHRPCI
The modem is already in dual mode of V.90 and K56 Flex.



 CMVA56KLUPCI
The modem is already in dual mode of V.90 and K56 Flex.



 CMVM56KLUPCI
The modem is already in dual mode of V.90 and K56 Flex.



 CMVALU56KPCI
The modem is already in dual mode of V.90 and K56 Flex.



 CMV56KRAPCI
The modem is already in dual mode of V.90 and K56 Flex.



CMVB56KPCTEL
The modem is already in dual mode of V.90 and K56 Flex.



 CMV1456VQH-T
The modem is already in dual mode of V.90 and K56 Flex.



 ROCKET DELUXE
The modem is already in dual mode of V.90 and K56 Flex.



 ROCKET EXPRESS
The modem is already in dual mode of V.90 and K56 Flex.



 PHOEBE 2000
The modem is already in dual mode of V.90 and K56 Flex.
